IEC 60335-2-84 Toilet Seat Cover Mechanical Strength & Durability Test Machine

MOQ:	1
価格:	交渉可能
標準パッケージ:	合板ケース
配達期間:	30日
支払方法:	T/T
供給能力:	1ヶ月あたりの5

起源の場所

ブランド名

Sinuo

Calibration Certificate (Cost Additional)

モデル番号

SN1901C

圧力範囲:

0～2000N

荷重センサーの精度:

クラス0.5

テスト頻度:

10～20サイクル/分

シリンダーの直径:

Φ50 mm

シリンダストローク:

125 mm

力の時間:

0 ～ 99.9 秒で調整可能

サイクルカウンタ:

0～999999 プログラム可能

オープニングアングル:

≥70°調整可能

ハイライト:

IEC 60335-2-84 toilet seat test machine

toilet seat cover durability tester

mechanical strength testing equipment for toilet seats

製品説明

IEC 60335-2-84 Toilet Seat Cover Mechanical Strength & Durability Test Machine

The Toilet Seat Cover Mechanical Strength and Durability Testing Machine is specially designed to evaluate the mechanical performance and service life of toilet seats and covers used in intelligent toilet appliances and sanitary products. This equipment simulates real operating conditions including opening and closing cycles, impact loads, static pressure, and side forces to verify the structural reliability of toilet seat assemblies.

Developed in accordance with IEC 60335-2-84 requirements, this testing system ensures that toilet seat components used in household and similar appliances meet international safety and durability standards. The machine features a servo motor drive system combined with computer and software control, enabling precise control of force, motion angle, and testing cycles.

Main Test Functions

Opening and Closing Life Cycle Test: Repeatedly opens and closes toilet seat and cover to preset angles to simulate long-term daily usage, evaluating hinge durability and structural stability
Slow Closing Performance Test: Measures closing time to evaluate damping mechanism and soft-closing performance
High Pressure Test: Forces seat cover to open and close repeatedly under controlled conditions to assess slow-drop mechanism reliability
Static Load Strength Test: Applies vertical load through steel and rubber pressing device to simulate user weight
Impact Resistance Test: Applies repetitive dynamic loads to toilet seat surface at specified frequency
Side Force Durability Test: Applies up to 890 N force alternately to both sides of seat to simulate uneven loads

Key Features

Designed according to IEC 60335-2-84 international testing standard
Computer and software control system for easy parameter setting
High-precision servo motor drive ensures stable motion control
Multiple independent test stations for improved testing efficiency
Adjustable test parameters including force, angle, and cycle times
High accuracy load sensor (0-2000N, class 0.5)
Strong aluminum frame structure for long-term laboratory use
Automatic data recording and real-time monitoring

Technical Specifications

Parameter	Specification
Test Stations	Three independent stations
Pressure Range	0-2000 N
Load Sensor Accuracy	Class 0.5
Test Frequency	10-20 cycles/min
Cylinder Diameter	Φ50 mm
Cylinder Stroke	125 mm
Force Angle	Adjustable
Force Time	0-99.9 s adjustable
Opening Angle	≥70° adjustable
Motor	400 W servo motor
Control Method	Computer + software control
Structure	Aluminum frame with test platform
Cycle Counter	0-999999 programmable
Power Supply	AC220V 60Hz
Equipment Size	Approx. 2500 × 700 × 1400 mm

Frequently Asked Questions

What standard is used for toilet seat mechanical strength testing?

The testing equipment is designed according to IEC 60335-2-84, which specifies safety requirements for toilet appliances and their mechanical components.

What tests can this machine perform?

The machine can perform opening and closing durability tests, slow closing performance tests, static load tests, impact resistance tests, and side force strength tests.

What control system does the equipment use?

The equipment uses a computer and dedicated software control system, allowing precise parameter adjustment and automatic data recording.

Who typically uses this equipment?

The machine is widely used by toilet seat manufacturers, appliance laboratories, and certification testing institutions.

Product Images
